Aquasorb A-30B/Bp is a sorption dehumidifier that condenses out the moisture. The chassis is made of stainless steel, which is especially important in condensing units. The rotor is, as always, washable. All energy is accumulated in the dry air. Aquasorb operates at dew-points below 0°C.
DR-010B is a handy dehumidifier that weighs only 12 kg.
All dehumidifiers from DST with the prefix DR are comprised of a single phase unit in stainless steel.
DC-10 weighs only 15 kg and dehumidifies according to the Consorb-principle. The DC-10 dehumidifier is maintenance friendly, has a long lifetime and rust free chassis.
DR-20B is stainless steel with sturdy handles and robust feet so that the unit is easier to stack. DR-20B is used for example for the dehumidification of military stores, water damaged houses and hydroelectric power stations. They are even used as permanent installations in buildings with mould problems.
* Dehumidifying capacity at 20°C / 60%RH.
DR-30D is the big brother of the DR-20B but with a larger dehumidifying capacity. DR-30D is used for the dehumidification of water damaged houses and warehouses as well as being used as a permanent installation in buildings with mould problems.
DR-31 T10 in stainless steel may be used for the dehumidification of warehouses, archives or other smaller spaces.The DR-31 dehumidifies according to the Recusorb-principle.
DR-40 is designed wholly in stainless steel with a highly effective SSCR-rotor from Seibu Giken.
DR-40 is a powerful single phase dehumidifier fitted with practical handles.
DC-031B is a portable single phase unit in stainless steel. DC-031B dehumidifies according to the Consorb-principle, see Technology in the main menu for further information on DST’s dehumidification principles.
DR-50 is maintenance friendly with components that are easy to strip down.
DR-50 is perfect for example for dry and chilled storage, water damage restoration and other applications that demands a controlled level of humidity.
The DC-50 has a similar housing to the DR-50 but runs with two fans.
This unit is the right choice when you need to re-circulate air in a room, and have a big difference in moisture content between room air and outdoor air.
Mid-range industrial desiccant dehumidifiers for medium volume dry air stores and sports halls, museums, small clean rooms and manufacturing processes.
Manufactured in 2333 stainless steel, these units include internal heat recovery, electric reactivation and Auto-Manual mode switching. Pre-wired for simple humidistat control as standard, units are also available for two 2 step binary control (from EH4 2 step controller) or linear capacity control (from EH3 PI controller or BMS control signal).
Dehumidifier R-060BR can also be made a mobile dehumidifier, placed on a wagon, and is used for serious water damages.
Mid-range industrial desiccant dehumidifiers for medium volume dry air stores and sports halls, museums, small clean rooms and manufacturing processes.
Manufactured in 2333 stainless steel, these units include internal heat recovery, electric reactivation and Auto-Manual mode switching. Pre-wired for simple humidistat control as standard, units are also available for two 2 step binary control (from EH4 2 step controller) or linear capacity control (from EH3 PI controller or BMS control signal).
Industrial dehumidifiers using desiccant technology, for large warehouses, cold stores, ice rinks and sports halls; chemical, pharmaceutical and confectionery manufacturing processes.
Manufactured in aluzinc, these units include internal heat recovery as standard, and are available with electric, steam or direct fired gas reactivation. Capacity control options include simple On/Off, multi-stepped binary control and full PID linear control.
Owing to the PLC-control the user can have full control over the relative moisture and temperature in the room or construction area. It is possible to receive notification via an SMS from the dehumidifier if for example the set temperature level is exceeded.
Industrial dehumidifiers using desiccant technology, for large warehouses, cold stores, ice rinks and sports halls; chemical, pharmaceutical and confectionery manufacturing processes.
Manufactured in aluzinc, these units include internal heat recovery as standard, and are available with electric, steam or direct fired gas reactivation. Capacity control options include simple On/Off, multi-stepped binary control and full PID linear control.
Owing to the PLC-control the user can have full control over the relative moisture and temperature in the room or construction area. It is possible to receive notification via an SMS from the dehumidifier if for example the set temperature level is exceeded
The CZ dehumidifiers are uniqe as these units can actually combine hot water heater and electricity heater. They are built in aluzink and has an excellent deep drying ability. These units are suitable for high ambient water contents.
RZ-102 is a compact unit in galvanised steel with exterior fans. Recusorb RZ-102 is an industrial dehumidifiers using desiccant technology, for large warehouses, cold stores, ice rinks and sports halls; chemical, pharmaceutical and confectionery manufacturing processes.
Manufactured in aluzinc, these units include internal heat recovery as standard, and are available with electric, steam or direct fired gas reactivation. Capacity control options include simple On/Off, multi-stepped binary control and full PID linear control.
Fitted with PLC the dehumidifier can be controlled remotely by mobile telephone. Perfect for storage applications, ice rinks and museums/archives and other applications that demands a controlled level of humidity. Owing to the PLC-control the user can have full control over the relative moisture and temperature in the room or construction area. It is possible to receive notification via an SMS from the dehumidifier if for example the set temperature level is exceeded.
The CZ dehumidifiers are uniqe as these units can actually combine hot water heater and electricity heater. They are built in aluzink and has an excellent deep drying ability. These units are suitable for high ambient water contents.
The RF range is a series of compact dehumidifiers which have been developed to meet the varying needs of the process industry. The RF units are suitable for applications requiring complete solutions for dehumidifi cation, with moisture and temperature control.
Low energy consumption.
The Recusorb dehumidification principle involves integral heat recovery and hence low energy consumption.
You can choose from electricity, steam or gas for rotor regeneration so that you can always make the most of all energy options open to you. Energy saving systems combined with various options allow you to create a dehumidifier to suit the specific needs of each and every project.
Rotor options.
Seibu Giken DST also offers 4 different rotors for environments with special requirements; during pharmaceutical manufacturing, in the plastics industry, the manufacture of food and confectionery, the automotive industry, and others.
ExactAir Division (Dammam Branch) Kingdom of Saudi Arabia
Tamkeen Industrial Development Services Ltd Saudi Arabia
OHTS-Jordan Jordan
Proservice Egypt
Satisfy Thailand
Way Technovation Singapore
National Engineering Enterprises Pakistan
AAQ , Applied Air Quality Specialists Malaysia
Korhex Engineering Co., Ltd Korea
DST China China
Seibu Giken Ltd. Japan
India India
Kai Mei Environmental CO, Ltd. Hong Kong
AAAT Air And Aqua Tech Australia
SGAmerica (Seibu Giken America) U.S.A
K.I.R.S.C.H. GmbH Austria
Pentagra AS Ukraine
Tetisan Turkey
Frey- Aufbereitungstechnic für Gase GmbH Germany
Flair A.S. (Czech Republic) Czech Republic
Humidity Control Systems Ltd. United Kingdom
K.I.R.S.C.H Hrvaška Croatia
Delta-E AG Lufttrocknung Switzerland
FLAIR a.s. Slovakia Slovakia
Arktika Russia
Eurofilter Srl Romania
HUMITEK INGENIEROS, S.L. Spain
DST POLSKA Sp. z o.o. Poland
Alfsen og Gunderson AS Norway
D&F Techniek The Netherlands
K.I.R.S.C.H Hrvaška Slovenia
Angelantoni Life Science S.r.l. Milan AG division Italy
Varma & Velaverk Iceland
Coolair Ltd Ireland
AAC-Gerasimos G. Kalavrias Greece
C.B.K. L'Air Sec France
Kryotherm OY Finland
Klimaseade Estonia
DST Danmark ApS Denmark
Dehumidification principles
DSTs dehumidifiers are desiccant. The basic principle is that the air to be dehumidified is passed through the rotating rotor which adsorbs moisture. The moisture in the rotor is removed by a hot air stream.
Recusorb R operates using integrated heat recycling. During the rotor’s regeneration (green), heat is absorbed, and then recycled in the “purge zone”, where incoming air is pre-heated and partly dehumidified. Energy consumption falls and the dry air becomes both drier and cooler compared to other sorption dehumidifiers.
Like Recusorb R, Recusorb DR has heat recycling, but has a fan for both the dry airflow and the wet airflow. This makes installation simpler when you require overpressure in the room to be dehumidified. This principle is also suitable when you want to achieve very low dew points.
Econosorb combines a heat pump with the sorption rotor in a unique way, providing very low energy consumption and a low dry air temperature. Probably the most energy efficient dehumidifier on the market, with approximately 1/4 of the total energy consumption of regular sorption dehumidifiers. Econosorb has both condensation and wet air.
Frigosorb is a principle patented by DST. Frigosorb is used in applications where it is difficult to remove a wet air airflow. Thanks to the heat pump function Frigosorb is very energy-efficient, using approximately 1/3 of the total energy consumption of regular sorption dehumidifiers.
Aquasorb basically functions as a Consorb but the wet air flow is condensed in an air-chilled condenser instead of being led out. Thanks to the common fan for dry air and cool air, all energy is accumulated in the dry air. Aquasorb has a high dry airflow, which improves the drying effect.
